High Resolution
Suitable for 3.45um pixel pitch at F/2.8
Wide Field of View
Up to 100° Field of View.
Optical and Mechanical Specification Table
| Lens Parameter | Specification |
|---|---|
| Part Number | CIL570 |
| Format Type | 1/1.8" |
| EFL | 4mm |
| F# | 2.0 - 16 Adjustable |
| Resolution | 3MP (3.456μm) |
| Field of View | 100° @ 9.5mm |
| Image Circle | 9.5mm |
| Distortion | -2% TV |
| Weight | / |
| Filter | None |
| Working Distance | 50mm~infinity |
| Construction | All Glass |
Engineering & Quality Assured
US Engineering Support
Easy Global Shipment
Volume Production Ready
Find other C-Mount Lenses by browsing below or on our C-Mount Lens webpage.
