Lens Features
>150° HFoV
Wide Angle Viewing
10MP-12MP
Crisp Images for demanding 1.4um pixel size
CIL391 Technical Specifications
| Lens Parameter | Specification |
|---|---|
| Part Number | CIL391 |
| Focal Length (EFL) | 3.2mm |
| F-Number (F#) | 2.8 |
| Resolution | 12MP+ |
| Field of View | 122° @ 6.3mm image circle Calculate for your sensor |
| Image Circle | 8.1mm |
| Distortion | -5% F-Θ |
| Weight | 6g |
| IR Cut-Off Filter | Optional |
| Construction | All-Glass |
| Chief Ray Angle | 15° |
| Mechanical Variant | Detail |
|---|---|
| "-M12A" | BBAR Coating on L1, no IP-rating |
| "-M12B" | BBAR Coating on L1, IP67 |
Mechanical Drawing, Compatibility, and .STP Download
| Camera/Mount | Compatibility |
|---|---|
| Commonlands Compatible Mount | CLA024 |
| e-con Systems | 12-15mm tall mount |
| D3 Engineering | Yes |
| iDS XLS | Yes |
| Allied Vision | Yes |
| Basler Dart | Yes |
| The Imaging Source M12 Mount | Yes |
| Raspberry Pi HQ M12 mount | Yes |
